JOHNSON CONTROLS

SECTION 5 – TECHNICAL DATA

FORM 150.72-ICOM6

ISSUE DATE: 08/03/2022

ETHYLENE GLYCOL PROPYLENE GLYCOL

WEIGHT

TONS

COMPR

GPM F/

TON

PRESS

DROP

FREEZE

WEIGHT

TONS

COMPR

GPM F/

TON

PRESS

DROP

FREEZE

10.0 1.0 1.0 24.3 1.0 26.2 10.0 1.0 1.0 24.0 1.0 26.0

20.0 1.0 1.0 25.1 1.1 17.9 20.0 1.0 1.0 24.3 1.1 19.0

30.0 1.0 1.0 25.9 1.2 6.7 30.0 1.0 1.0 24.9 1.3 9.0

40.0 1.0 1.0 26.9 1.4 -8.1 40.0 1.0 1.0 25.6 1.4 -6.0

50.0 1.0 1.0 28.0 1.6 -28.9 50.0 0.9 1.0 26.6 1.7 -28.0

NOTE: Water Pressure Drop Curves may extend past the minimum and maximum water ow ranges.

TABLE 5 - ETHYLENE AND PROPYLENE GLYCOL CORRECTION FACTORS
