SECTION 5 – TECHNICAL DATA
TABLE 12 - WIRING LUGS
CHILLER
MODEL
VOLTS
1 PT SUPPLY
T. BLOCK
MOLDED CASE SWITCH
1 PT. SUPPLY
MOLDED CASE CIRCUIT
BREAKER 1 PT. SUPPLY
INSTALLED
LUG
INSTALLED
LUG
ALTERNATE
LUG
INSTALLED
LUG
ALTERNATE
LUG
YLAA0041
208 (1) # 6–500 — — (1) 4–300 —
230 (1) # 6–500 — — (1) 4–300 —
380 (1) # 6–500 — — (1) 4–300 —
460 (1) # 6–500 — — (1) 4–300 —
575 (1) # 6–500 — — (1) 4–300 —
YLAA0048
208 (1) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
230 (1) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
380 (1) # 6–500 (1) 6–350 — (1) 6–350 —
460 (1) # 6–500 (1) 6–350 — (1) 6–350 —
575 (1) # 6–500 (1) 6–350 — (1) 6–350 —
YLAA0058
208 (1) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
230 (1) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
380 (1) # 6–500 (1) 6–350 — (1) 6–350 —
460 (1) # 6–500 (1) 6–350 — (1) 6–350 —
575 (1) # 6–500 (1) 6–350 — (1) 6–350 —
YLAA0065
208 (2) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
230 (2) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
380 (1) # 6–500 (1) 250–500 (2) 3/0–250 (1) 6–350 —
460 (1) # 6–500 (1) 6–350 — (1) 6–350 —
575 (1) # 6–500 (1) 6–350 — (1) 6–350 —
YLAA0070
208 (2) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
230 (2) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
380 (1) # 6–500 (1) 6–350 — (1) 6–350 —
460 (1) # 6–500 (1) 6–350 — (1) 6–350 —
575 (1) # 6–500 (1) 6–350 — (1) 6–350 —
YLAA0080
208 (2) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
230 (2) # 6–500 (2) 250–500 (3) 2/0–400 (2) 3/0–250 (1) 250–500
380 (1) # 6–500 (2) 3/0–250 (1) 250–500 (1) 6–350 —
460 (1) # 6–500 (1) 6–350 — (1) 6–350 —
575 (1) # 6–500 (1) 6–350 — (1) 6–350 —
