JOHNSON CONTROLS
50
FORM 150.72-ICOM6
ISSUE DATE: 08/03/2022
SECTION 5 – TECHNICAL DATA
REFRIGERANT R-410A
YLAA
STANDARD EFFICIENCY UNITS
0070SE 0080SE 0089SE 0100SE 0120SE 0136SE 0155SE 0170SE
NOMINAL RATINGS
3
TONS
71.0 77.8 81.8 95.6 118.1 126.1 143.0 167.4
KW INPUT 77.5 86.3 93.0 111.5 134.6 142.6 165.0 192.1
EER 10.4 10.0 9.8 9.7 9.8 9.7 9.7 9.7
IPLV
16.1 15.6 15.8 14.5 15.0 15.8 15.8 15.6
GENERAL UNIT DATA
Length
116.1 116.1 116.1 142.7 142.7 187.7 187.7 232.7
Width 88 88 88 88 88 88 88 88
Height 94.2 94.2 94.2 94.2 94 94.2 94.2 94.2
Number Of Refrigerant Circuits
2 2 2 2 2 2 2 2
REFRIGERANT CHARGE, OPERATING
R-410A, CKT1/CKT2, lb
43/43 47/44 57/57 55/58 54/62 75/71 75/70 90/87
Oil Charge, CKT1/CKT2, gal 2.58/2.58 3.28/2.58 3.28/2.76 3.28/3.33 3.33/3.33 4.99/2.76 4.99/3.33 4.99/4.99
Shipping Weight 3578 3898 4168 4791 5183 6148 6414 7734
Operating Weight
3623 3954 4241 4864 5293 6232 6524 7818
COMPRESSORS, SCROLL TYPE
Compressors Per Circuit
3/3 3/3 3/3 3/2 2/2 3/3 3/2 3/3
Compressors Per Unit
6 6 6 5 4 6 5 6
NOMINAL TONS PER COMPRESSOR
Circuit 1
13 15 15 15 32 32 32 32
Circuit 2
13 13 15 32 32 15 32 32
CONDENSER
Total Face Area Ft
2
106.9 106.9 106.9 133.6 160.3 213.8 213.8 267.2
Number Of Rows 1 1 1 1 1 1 1 1
Fins Per Inch
20 20 20 20 20 20 20 20
CONDENSER FANS, LOW SOUND
Number Of Fans, CKT 1/CKT 2
2/2 2/2 2/2 3/2 3/3 4/4 4/4 5/5
Fan HP 2 2 2 2 2 2 2 2
Fan RPM 1160 1160 1160 1160 1160 1160 1160 1160
Total Chiller CFM
60000 60000 60000 75000 90000 120000 120000 150000
EVAPORATOR
Water Volume, gal
5.4 6.7 8.8 8.8 13.2 10.0 13.2 10.0
Maximum Water Side Pressure,
psig
150 150 150 150 150 150 150 150
Maximum Refrigerant Side
Pressure, psig
450 450 450 450 450 450 450 450
Minimum Chiller Water Flow
Rate, GPM
60 100 100 100 150 150 150 150
Maximum Chiller Water Flow
Rate, GPM
285 355 385 385 625 625 625 625
Water Connections Size, in.
3 3 3 3 3 4* 4* 4*
NOTES:
1. kW = Compressor Input Power.
2. EER = Chiller EER (includes power from compressors, fans, and the control panels 0.8 kW).
3. Rated in accordance with AHRI Standard 550/590 at an air on condenser temperature of 95°F and a leaving chilled water temperature of 44°F.
4. Additional rating information can be provided by your local Johnson Controls Sales O󰀩ce.
PHYSICAL DATA YLAA0041 – YLAA0230 60 HZ
TABLE 6 - PHYSICAL DATA (ENGLISH) 60 HZ
