SECTION 3 - OPTIVIEW™ CONTROL CENTER FUNCTIONS AND NAVIGATION
SLOT # DESCRIPTION
1799 Remote Modem Temperature Setpoint
1800 Selected Temperature Setpoint
1802 Remote Temperature Range
1803 Restart Temperature Offset
1804 Restart Temperature Offset
1805 Shutdown Temperature Offset
1806 Shutdown Temperature Setpoint
1818 Remote Digital Temperature Setpoint
SMART FREEZE PROTECTION
1815 Is Control Enabled
VARIABLE GEOMETRY DIFFUSER
8280 Active Stall Voltage
18305 Active Stall Voltage Type
18135 Mach Number
18137 Active High Limit
18138 Active Low Limit
8337 Stroke Calibration Complete
8338 VGD Stroke Calibration Command
8355 VGD Fault Code
8353 VGD Actuator Fault
8354 VGD Shutdown Command
17408 Discharge Pressure
VARIABLE SPEED DRIVE
2305 Motor Run
2306 Motor % FLA
3047 VSD Fault
18085 Input % Full Load Amps
2823 VSD Output Voltage
2822 VSD Output Frequency
20788 Max Chiller Frequency
2818 Input Power
2819 Input kW Hours
2878 L1 Voltage Total Harmonic Distortion
2879 L2 Voltage Total Harmonic Distortion
2880 L3 Voltage Total Harmonic Distortion
3014 L1 Input Current Total Demand Distortion
3015 L2 Input Current Total Demand Distortion
3016 L3 Input Current Total Demand Distortion
3017 Input kVA
2869 Input Power Factor
2306 Motor % Full Load Amps
20784 VSD Command
3051 VSD Control State
3050 VSD Inverter State
3058 Precharge Active
3044 DC Bus Regulating
SLOT # DESCRIPTION
3057 Precharge Complete
3027 DC Bus Voltage
2829 Cooling System
3053 L1 Input Voltage (Peak)
3054 L2 Input Voltage (Peak)
3055 L3 Input Voltage (Peak)
2872 L1 Input Voltage (RMS)
2873 L2 Input Voltage (RMS)
2874 L3 Input Voltage (RMS)
3008 L1 Input Current (RMS)
3009 L2 Input Current (RMS)
3010 L3 Input Current (RMS)
3018 Phase A Output Voltage (RMS)
3019 Phase B Output Voltage (RMS)
3020 Phase C Output Voltage (RMS)
3021 Phase A Output Current (RMS)
3022 Phase B Output Current (RMS)
3023 Phase C Output Current (RMS)
3031 Phase A Rectier Baseplate Temperature
3032 Phase B Rectier Baseplate Temperature
3033 Phase C Rectier Baseplate Temperature
3034 Phase A Inverter Baseplate Temperature
3035 Phase B Inverter Baseplate Temperature
3036 Phase C Inverter Baseplate Temperature
3029 Internal Ambient Temperature 1
3030 Internal Ambient Temperature 2
MOTOR MONITORING
3059 Motor Winding Phase A Temp Z1 End
3060 Motor Winding Phase A Temp Z2 End
3061 Motor Winding Phase B Temp Z1 End
3062 Motor Winding Phase B Temp Z2 End
3063 Motor Winding Phase C Temp Z1 End
3064 Motor Winding Phase C Temp Z2 End
19148 Average Winding Temperature
2362 Motor Housing Temperature
18361 Motor Housing Temperature Setpoint
18371 Motor Winding Temperature Setpoint
18362 Motor Cooling Valve Command
18396 Motor Cooling Control State
18397 Estimated Rotor Temperature
18398 Ambient Dew Point Temperature
CAPACITY CONTROL
2822 VSD Output Frequency
18023 HGBP Command
18041 Condenser Pressure Override Threshold
18042 Evaporator Pressure Override Threshold
