Routine Maintenance
Cleaning Schedule and Procedures
130
P1056468-002 7/3/13
Clean the Snap Plate
Clean the snap plate when label adhesive or a label is stuck to the underside. Figure 12 shows
the location of the snap plate.
Figure 12 • Snap Plate Location
To clean the snap plate, complete these steps:
1.
2.
Important • Be careful not to bend or twist the metal snap plate as you remove it from or
insert it into the printer.
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Turn off (O) the printer, and disconnect the AC power cord and all data cables.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the printhead and remove the media and ribbon (if used).
To Next Page
