Specifications
Media Specifications
164
P1056468-002 7/3/13
Media Specifications
Use the correct size and type of labels for best performance. Refer to the tables that follow for
specifications.
110
Important • Media registration and minimum label length are affected by label type and
width, ribbon type, print speed, and printer mode of operation. Performance improves as
these factors are optimized. Zebra recommends qualifying any application with thorough
testing.
Media Specifications 203 dpi 300 dpi
Minimum label length Tear-Off 0.7 in. (18 mm) 0.7 in. (18 mm)
Peel-Off 0.5 in. (13 mm) 0.5 in. (13 mm)
Cutter 1.5 in. (38 mm) 1.5 in. (38 mm)
Rewind 0.25 in. (6 mm) 0.25 in. (6 mm)
Total media width
(label + backing, if any)
Minimum 0.79 in. (20 mm) 0.79 in. (20 mm)
Maximum 4.5 in. (114 mm) 4.5 in. (114 mm)
Total thickness
(includes backing, if any)
0.003 in. (0.076 mm) 0.003 in. (0.076 mm)
0.012 in. (0.305 mm) 0.012 in. (0.305 mm)
Cutter maximum full-width media thickness 0.009 in. (0.23 mm) 0.009 in. (0.23 mm)
Roll media core inside diameter 3 in. (76 mm) 3 in. (76 mm)
Maximum roll diameter on 3 in. (76 mm) core 8.0 in. (203 mm) 8.0 in. (203 mm)
Interlabel gap Minimum 0.079 in. (2 mm) 0.079 in. (2 mm)
Preferred 0.118 in. (3 mm) 0.118 in. (3 mm)
Maximum No more than the calibrated
length of the label.
No more than the calibrated
length of the label.
Maximum internal fanfold media pack size
(label + backing): L × W×H
8.0×4.5×4.5 in.
(203×114×114 mm)
8.0×4.5×4.5 in.
(203×114×114 mm)
Ticket/tag sensing notch: L × W 0.12×0.25 in. (3×6 mm) 0.12×0.25 in. (3×6 mm)
Ticket/tag sensing hole diameter 0.125 in. (3 mm) 0.125 in. (3 mm)
Label registration tolerance (vertical) ± 0.06 in. (± 1.5 mm) ± 0.06 in. (± 1.5 mm)
Label registration tolerance (horizontal) ± 0.06 in. (± 1.5 mm) ± 0.06 in. (± 1.5 mm)
Maximum media density 0.5 ODU 0.5 ODU
