SSI Interface 8 - 11
Baud Rate (continued)
Parity
Parameter # 158 (SSI # 9Eh)
A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to
host device requirements.
•
Select Odd parity and the parity bit has a value 0 or 1, based on data, to ensure that an odd number of 1
bits is contained in the coded character.
•
Select Even parity and the parity bit has a value 0 or 1, based on data, to ensure that an even number of
1 bits is contained in the coded character.
•
If no parity is required, select None.
Baud Rate 460,800
(14)
Baud Rate 921,600
(15)
Odd
(0)
Even
(1)
*None
(4)
To Next Page
