Zip HydroTap All-In-One BC100/125A User Manual

HydroTap Installation and Operating Instructions - 89650UK - August 2011 v1.02 Page 13 of 24
MAINS AMBIENT WATER SUPPLY
(ISOLATION VALVE NOT SUPPLIED)
MAINS HOT WATER SUPPLY
(ISOLATION VALVE NOT SUPPLIED)
65
200
BENCHTOP
CABINET DOOR
4mm BUFFER
PAD TO ENSURE
VENTILATION GAP
SILICONE HOSE FROM
BOILING WATER TANK
IN HYDROTAP UNIT
TO TAP
SILICONE HOSE FROM
CHILLED WATER TANK
IN HYDROTAP UNIT
TO TAP
BRAIDED HOSE BH2
FROM DOMESTIC HOT WATER
SUPPLY TO TAP
BRAIDED HOSE BH1
FROM MAINS WATER
SUPPLY TO TAP
C
ONE HOSE
O
M STEAM VENT
H
YDROTAP UNIT
T
AP
ALL IN ONE TAP-MAINS VERSION

Zip HydroTap All-In-One BC100/125A Specifications

General

Brand	Zip
Model	HydroTap All-In-One BC100/125A
Category	Water Heater
Language	English
