5 Configure the Internet

Parameter Description

Packets Classification Criterion

All Interface Set radiobox On to enable all Interface.

Ingress If setting radiobox Off to disable all Interface, specify the data

traffic direction.

Source MAC Address Source host MAC address.

Destination MAC Address Destination host MAC address.

802.1p Specify the 802.1p value to modify the service priority.

VLAN ID Identifies a VLAN. Range: 0–4094. To ensure normal service

operation, the VLAN ID must be the same as that set in upper-

layer configuration.

Level 2 Protocol The level 2 protocol includes: Unconcerned, IPv4, IPv6, ARP and

PPPoE.

Source IP Source host IP address.

Destination IP Destination host IP address.

DSCP DSCP value.

Level 3 Protocol The Level 3 Protocol includes: Unconcerned, TCP, UDP and

ICMP.

Source Port Source port number of the matching packets.

Destination Port Destination port number of the matching packets.

TCP ACK Set radiobox On to enable the function of TCP ACK.

Packets Classification Result

802.1p Re-marking 802.1p identifier value.

DSCP Re-marking DSCP identifier.

Queue Priority Range:1-8.

3. Click Apply button to apply the changes.

5.4 Configure the Security

5.4.1 Configure the Firewall Level

The section describes how to configure firewall level.

SJ-20200429083356-004 | 2020-07-23(R1.0) 5-11
