7 Configure the Management and Diagnosis
Table 7-9 Parameter Descriptions for the Remote Log Management
Parameter Description
Remote Log Click On to enable the remote log function.
3. Click Apply button to apply the changes.
7.8 Network Diagnosis
The section describes how to diagnosis. Diagnosis provides the parameters of the
Diagnosis configuration features.
The relevant information includes ping diagnosis, trace route diagnosis, DSL line
diagnosis and simulation.
Steps
Ping Diagnosis
1. On the main page of the ZXHN H3601, select Management&Diagnosis >
Diagnosis to the Diagnosis page.
2. Click to open Ping Diagnosis page, see Figure 7-17.
Figure 7-17 Ping Diagnosis Page
3. Set the parameters. For a description of the parameters, refer to Table 7-10.
SJ-20200429083356-004 | 2020-07-23(R1.0) 7-13
