5 Configure the Internet

Figure 5-21 Port Forwarding Configuration Page

2. Configure the Port Forwarding parameters.

Table 5-14 lists the Port Forwarding settings parameters.

Table 5-14 Parameter Descriptions for the Port Forwarding

Parameter Description

On/Off Set radiobox On to enable the port forwarding function.

Name Virtual host name, which cannot be null.

Protocol Protocol name, including TCP, UDP, TCP AND UDP.

The default protocol is TCP.

WAN Host IP Address IP address segment of the WAN-side hosts.

LAN Host IP address of the LAN-side host.

WAN Port Port segment of the WAN-side hosts.

LAN Host Port Port number range of the LAN-side host. Range: 1-65535.

3. Click Apply button to apply the changes.

5.5 Configure the Parental Controls

The section describes how to configure parental controls.

Steps

1. On the main page of the ZXHN H3601, select Internet > Parental Controls to the

Parental Controls page, see Figure 5-22.

SJ-20200429083356-004 | 2020-07-23(R1.0) 5-21
