Zte ZXR10 2928E-PS User Manual

Chapter4ServiceConguration
CommandFunction
zte(cfg)#setethernet-oamport<portlist>link-monitor{enable|disable}
Enablesordisableslinkmonitor
function.
zte(cfg)#setethernet-oamport<portlist>link-monitorsymbol-period
threshold<1-65535>window<1-65535>
Setsthesymbolperiodeventwhichis
usedforlinkmonitor.
zte(cfg)#setethernet-oamport<portlist>link-monitorframethreshold
<1-65535>window<1-60>
Setstheerrorframe.
zte(cfg)#setethernet-oamport<portlist>link-monitorframe-period
threshold<1-65535>window<1-600000>
Setstheperiodoferrorframe.
zte(cfg)#setethernet-oamport<portlist>link-monitorframe-seconds
threshold<1-900>window<10-900>
Setserrorframesummary.
showethernet-oam(allcongurationmodes)
DisplaysOAMglobalconguration
information.
showethernet-oamport(allcongurationmodes)
DisplaysOAMportsummary
information.
showethernet-oamport<portlist>discovery(allcongurationmodes)DisplaysportOAMdiscoverystate.
showethernet-oamport<portlist>statistics(allcongurationmodes)
DisplaysportOAMstatistics
information.
showethernet-oamport<portlist>link-monitor(allcongurationmodes)
DisplaysportOAMlinkevent
congurationandstate.
OAMRemoteLoopbackCongurationInstance
lCongurationDescription
OAMmonitorfunctioncannotifytheabnormalframeoflinkreceivertothelocal.The
functionisbasedonOAMdiscovery.AsshowninFigure4-45,Theuserlogsinto
theswitchthroughconsoleportandconguresOAM.EnableOAMandtheportlink
monitoroftheotherend.Thentheerrorframeandtheerrorsymbolcanbedetected
andnotifylocalswitch.
Figure4-45RemoteLoopNetwork
lCongurationProcedure
1.CongurationofswitchA:
zte(cfg)#setethernet-oamen
zte(cfg)#setethernet-oamport1en
2.CongurationofswitchB:
4-113
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2928E-PS Specifications

General

Model	ZXR10 2928E-PS
Category	Switch
PoE	Yes
Switching Capacity	128 Gbps
MAC Address Table Size	16K
VLANs	4K
Jumbo Frame	9K
Dimensions	440 x 260 x 44 mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Power Supply	AC 100-240V
Power Consumption	400W (PoE Max)
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% RH
Ports	24 x 10/100/1000BASE-T, 4 x 1000BASE-X SFP
