ZXR102900ESeriesCongurationGuide
Figure4-48VLANMappingCongurationInstance
SW1andSW2areconguredinthesameway.TakeSW1asexample.
lCongurationProcedure
ThefollowingexampleshowshowtoconguretheVLANMappinginstance.
zte(cfg)#setvlan1-100,1000addport1,24tag
zte(cfg)#setvlan1-100,1000enable
zte(cfg)#setvlanmappingsession1customer-port1customer-vlan1-100
uplink-vlan1000
lCongurationVerication
ThefollowingexampleshowshowtoshowtheSVLANinstance.
zte(cfg)#showvlanmapping
Sessionnumber:1
CustomerPort:1
CustomerVlanList:1-100
UplinkVlan:1000
4.33sFlowConguration
ThesFlowcongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setsflowagent-address<A.B.C.D>[udp-port<1-65535>]SetstheIPaddressofansFlowagent.
4-122
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential
