Chapter4ServiceConguration
CommandFunction
zte(cfg)#cleartrunk<trunklist>{multicast-filter}Clearstheagoftheportmulticastlter.
LACPCongurationInstance
lCongurationDescription
AsshowninFigure4-4,switchAandswitchBareconnectedthroughtheaggregation
port(bindingtheport15andport16).Port1ofswitchAandport2ofswitchBbelong
toVLAN2.Port3ofswitchAandport4ofswitchBbelongtoVLAN3.Membersof
thesameVLANcancommunicatewitheachother.
Figure4-4LACPCongurationInstance
lCongurationProcedure
1.ThedetailedcongurationofswitchAisasfollows:
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator3addport15-16
zte(cfg)#setlacpaggregator3modedynamic
zte(cfg)#setlacpload-balancepacketL2
zte(cfg)#setvlan2addtrunk3tag
zte(cfg)#setvlan2addport1untag
zte(cfg)#setvlan3addtrunk3tag
zte(cfg)#setvlan3addport3untag
zte(cfg)#setport1pvid2
zte(cfg)#setport3pvid3
zte(cfg)#setvlan2-3enable
2.ThedetailedcongurationofswitchBisasfollows:
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator3addport15-16
zte(cfg)#setlacpaggregator3modedynamic
zte(cfg)#setlacpload-balancepacketL2
zte(cfg)#setvlan2addtrunk3tag
zte(cfg)#setvlan2addport2untag
4-19
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2928E-PS Specifications

General

Model	ZXR10 2928E-PS
Category	Switch
PoE	Yes
Switching Capacity	128 Gbps
MAC Address Table Size	16K
VLANs	4K
Jumbo Frame	9K
Dimensions	440 x 260 x 44 mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Power Supply	AC 100-240V
Power Consumption	400W (PoE Max)
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% RH
Ports	24 x 10/100/1000BASE-T, 4 x 1000BASE-X SFP
