ZXR103900A/3200ASeriesHardwareInstallationManual
ZXR103228A-FI
ThechassisheightofZXR103228A-FIis1U(1U=44.45mm).
ZXR103228A-FIcansupport24100MpbsEthernetopticalinter-
faces,whichisSFPand2xedgigabitEthernetopticalinterfaces.
TheelectricalinterfaceisRJ45,supportingtwistedpairsofCAT5
andabove.TheopticalinterfaceisSFP ,supportingvariousgigabit
and100Mpbs-opticalmodulesmeetingSFPstandard.Thereisone
slotonthefrontpanel,supportingfourdifferentinterfacecards.
ThefrontpanelofZXR103228A-FIisshowninFigure8.
FIGURE8ZXR103228A-FIFRONTPANEL
ThebackplaneofACpowersupplyinZXR103228A-FIisshown
inFigure9.
FIGURE9ZXR103228A-FIBACKPLANE(AC)
ThebackplaneofDCpowersupplyinZXR103228A-FIisshown
inFigure10.
FIGURE10ZXR103228A-FIBACKPLANE(DC)
ZXR103252A
ThechassisheightofZXR103252Ais1U(1U=44.45mm).ZXR10
3252Acansupport48100MpbsEthernetelectricalinterfacesand
4xedgigabitEthernetopticalinterfaces.Theelectricalinterface
isRJ45,supportingtwistedpairsofCAT5andabove.Theoptical
interfaceisSFP ,supportingvariousgigabitmodulesmeetingSFP
standard.
ThefrontpanelofZXR103252AisshowninFigure11
.
FIGURE11ZXR103252AFRONTPANEL
ThebackplaneofACpowersupplyinZXR103252Aisshownin
Figure12.
12CondentialandProprietaryInformationofZTECORPORATION
