ZXR103900A/3200ASeriesHardwareInstallationManual
FIGURE39DCCABLEC-PWR-084
ThecorrespondencebetweentwoendsofDCcablesare
showninT able7
.
TABLE7DCCABLESTWOENDSCORRESPONDENCE
EndAEndBPowerSignal
1B1
-48VGND
2B2-48V
TheendAisconnectedto-48Vinputsocket.Connecttwo
terminalsonendBaccordingtolabelspastedoneachcon-
ductor .TheB1isconnectedto-48VGNDofDCpowersup-
ply,andB2isconnectedto-48V .Theconductorlabelson
endBaredescribedinTable8.
TABLE8LABEL
EndB1EndB2
-48VGND-48V
ii.DCstandbypowerC-PWR-072isshowninFigure40.
FIGURE40DCSTANDBYPOWERC-PWR-072
ThecorrespondencebetweentwoendsofDCcablesare
showninT able9
.
30CondentialandProprietaryInformationofZTECORPORATION
