ZXR10 ZSR V2 Series Router Product Description
56 ZTE Confidential & Proprietary
3.11 Network Management Features
3.11.1 NetNumen™ Integrated Network Management Platform
3.11.1.1 Network Management Networking
ZTE NetNumen™ is a network management system constructed on the data
communication network. It can take integrated maintenance and management of various
types of network equipment in a wide area and complicated application environment.
In-band management and out-band network management can be adopted between
NetNumen™ network management system and ZXR10 ZSR V2.
 In-band management
In-band management means network management information and service data are
transported in one channel. No extra DCN should be built. NetNumen™ network
management system can fulfill its task as long as it’s connected to the nearby network
equipment with related SNMP parameters configured.
 Out-band management
Out-band management means network management information is independent from
service data. The network management information is transported inside network
management system. Extra DCN network is needed. NetNumen™ network management
is connected to ZXR10 ZSR V2 via its out-band management interface. Network
management information and service information are transmitted independently and
respectively.
3.11.1.2 NetNumen™ Network Management System
The NetNumen™ U31 (BN) developed by ZTE is a unified network management system
aiming at managing SDH, MSTP, WDM, PTN, OTN and IP device (router and switch,
etc.). It includes the management of the network element, network, and service. The
network management provides the following services:
 Fault management ensures stable network operation.

Zte ZXR10 ZSR V2 Series Specifications

General

Series	ZXR10 ZSR V2 Series
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Ports	GE, 10GE
Storage Humidity	5% to 95% (non-condensing)
