ZXR10 ZSR V2 Series Router Product Description
58 ZTE Confidential & Proprietary
3.11.3 Network Layer Inspection
The ZXR10 ZSR V2 provides multiple network layer inspection services on the basis of
ping and trace, e.g. IP Ping, IP Trace, LSP Ping, LSP Trace, multicast Ping, and
multicast Trace.
3.12 System Operation and Maintenance
3.12.1 Multiple Configuration Methods
The ZXR10 ZSR V2 provides multiple device login and management configuration
modes. So that, the user can chose the best configuration mode as per different
scenarios.
 Serial port connection configuration
 Telnet connection configuration
 Secure shell protocol (SSH) connection configuration
 SNMP connection configuration
 Upgrade version by USB
 Auto-config
 Upgrade version batch by network management
3.12.2 System Policing and Maintenance
The ZXR10 ZSR V2 supports multiple ways to monitor, manage and maintain the device.
As a result, corresponding approaches are provided for different aberrance. The
specifications in running the device can also be offered.
The device policing includes:
 There’re indicators in the power supply, fan, MPFU and all PIUs to show their
running status.
 The fan monitoring is handled by the fan module. In addition to inspect the unit
on-board information and the status, it can also support changing the fan speed

Zte ZXR10 ZSR V2 Series Specifications

General

Series	ZXR10 ZSR V2 Series
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Ports	GE, 10GE
Storage Humidity	5% to 95% (non-condensing)
