Function block name
Edition 1 logical nodes
Edition 2 logical nodes
CVGAPC
GF2LLN0
GF2MMXN
GF2PHAR
GF2PTOV
GF2PTUC
GF2PTUV
GF2PVOC
PH1PTRC
GF2MMXN
GF2PHAR
GF2PTOV
GF2PTUC
GF2PTUV
GF2PVOC
PH1PTRC
CVMMXN
CVMMXN
CVMMXN
DPGAPC
DPGGIO
DPGAPC
DRPRDRE
DRPRDRE
DRPRDRE
EF4PTOC
EF4LLN0
EF4PTRC
EF4RDIR
GEN4PHAR
PH1PTOC
EF4PTRC
EF4RDIR
GEN4PHAR
PH1PTOC
EFPIOC
EFPIOC
EFPIOC
ETPMMTR
ETPMMTR
ETPMMTR
FUFSPVC
SDDRFUF
FUFSPVC
HZPDIF
HZPDIF
HZPDIF
INDCALH
INDCALH
INDCALH
ITBGAPC
IB16FCVB
ITBGAPC
L4UFCNT
L4UFCNT
L4UFCNT
LCPTTR
LCPTTR
LCPTTR
LD0LLN0
LLN0
LLN0
LDLPSCH
LDLPDIF
LDLPSCH
LFPTTR
LFPTTR
LFPTTR
LMBRFLO
LMBRFLO
LMBRFLO
LOVPTUV
LOVPTUV
LOVPTUV
LPHD
LPHD
LPHD
LT3CPDIF
LT3CPDIF
LT3CGAPC
LT3CPDIF
LT3CPHAR
LT3CPTRC
MVGAPC
MVGGIO
MVGAPC
NS4PTOC
EF4LLN0
EF4PTRC
EF4RDIR
GEN4PHAR
PH1PTOC
EF4PTRC
EF4RDIR
PH1PTOC
OC4PTOC
OC4LLN0
GEN4PHAR
PH3PTOC
PH3PTRC
GEN4PHAR
PH3PTOC
PH3PTRC
OV2PTOV
GEN2LLN0
OV2PTOV
PH1PTRC
OV2PTOV
PH1PTRC
PCFCNT
PCGGIO
PCFCNT
Table continues on next page
