Section 2 Installation Mounting AC 800M Units onto DIN-Rail
3BSE 027 941 R301 51
Figure 8. Baseplate Locking Device
Figure 9. DIN-rail Mounting of AC 800M Units
1. OPEN 2. SLIDE 3. LOCKED
Lugs for extra screws
to provide secure
mounting in locations
subject to vibration
