Installation in Cabinets Section 2 Installation
88 3BSE 027 941 R301
Figure 24. Wall Cabinet – Dual Power Supply (Local/Field) Arrangement
Mains Breaker
Unit
SD821
24 V Distribution
(Units)
(Units in Cabinet)
SD821
(Field)
24 V Distribution
(Field Equipment)
