CP-C 24/5.0 Section 9 Technical Data
142 M&I – AC 900F Controller
Mechanical data
Electrical connection
Ambient temperature
Certificates
Dimensions W x H x D 60 x 130 mm x 137 mm
Weight approx. 0.96 kg
Installation DIN rail
Mounting position Horizontal
Minimum distance between devices > 10 mm horizontal, > 80 mm vertical
Type of protection IP 20
Wire size 0.2 - 2.5 mm
2
Wire type Rigid, finely stranded with/without wire
end ferrule
Protection class I
Operation with derating - 25 ... +70 °C
Operation at rated current 0 ... +60 °C
Storage - 40 ... +85 °C
Declaration of conformity CE
Approvals cULus
UL Class 1 Div 2 (Groups A, B, C, D)
EAC
The voltage as well as the input and output wiring must comply with the
requirements specified for Class I, Div. 2 - Article 501-10(B) (1) NEC.
