Appendix A – ACS/ACC/ACP 601 Technical Data
ACS/ACC/ACP 601 Frequency Converters A-5
Diagram
Output current for ACS/ACC/ACP 601 with degree of protection IP 54
and with ambient temperature from 25 °C (77 °F) to 40 °C (104 °F) is
presented in the diagram below.
I
2N
total rms output current for normal
use.
Note:
The output current in heavy-duty use (
I
2hd
) must be smaller or
equal than the derated
I
2N
.
24 26 28 30 32 34 36 38 40
t
( °C)
75 79 82 86 90 93 97 100 104
t
( °F)
100
95
90
85
80
75
70
65
60
Curve 1
(100 %
no derating)
Curve 2 Curve 3 Curve 4 Curve 5
ACx 601-0005-3 ACx 601-0006-3 ACx 601-0011-3 ACx 601-0009-3 ACx 601-0016-3
ACx 601-0006-5 ACx 601-0009-5 ACx 601-0020-3 ACx 601-0070-3 ACx 601-0020-5
ACx 601-0009-6 ACx 601-0016-6 ACx 601-0025-3 ACx 601-0011-5 ACx 601-0070-6
ACx 601-0025-5 ACx 601-0030-3 ACx 601-0100-5
ACx 601-0030-5 ACx 601-0040-3 ACx 601-0040-6
ACx 601-0040-5 ACx 601-0050-3 ACx 601-0050-6
ACx 601-0070-5 ACx 601-0060-3
ACx 601-0011-6 ACx 601-0016-5
ACx 601-0050-5
ACx 601-0060-5
ACx 601-0020-6
ACx 601-0025-6
ACx 601-0030-6
ACx 601-0060-6
% of
I
2N
2
3
4
5
1
