ABB ACS 600 User Manual

Appendix A – ACS/ACC/ACP 601 Technical Data
A-10 ACS/ACC/ACP 601 Frequency Converters
Cable Entries
Mains and motor cable terminal sizes (per phase) and tightening
torques for the ACS/ACC/ACP 601 with cable diameters accepted by
the rubber glands are given below.
*)
35 mm
2
copper cable and 50 mm
2
aluminium fits in.
1)
The maximum acceptable size of the mains and motor cable is 3x120+70 (3x(AWG 0000) + AWG 00); cross-
sectional areas of copper conductors in mm
2
, 3 x phase conductor + PE conductor). Aluminium cable cannot
be connected due to cable lug size.
ACx 600 Type
U1,V1,W1 / U2,V2,W2 Earthing PE Braking
Terminal Cable
Ø
Tightening
Torque
Terminal Cable
Ø
UDC+,
UDC-
mm
2
AWG mm in Nm Ft/lbs mm
2
AWG mm in mm
2
ACx 601-0005-3
ACx 601-0006-5
ACx 601-0006-3
ACx 601-0009-5
ACx 601-0009-3
ACx 601-0011-5
6 8 14...20 0.55...0.79 1.5...1.8 1.1...1.3 6 8 10...14 0.39...0.55 6
ACx 601-0009-6
ACx 601-0011-6
ACx 601-0011-3
ACx 601-0016-5
ACx 601-0016-6
ACx 601-0016-3
ACx 601-0020-5
ACx 601-0020-6
10 6 14...20 0.55...0.79 1.5...1.8 1.1...1.3 10 6 10...14 0.39...0.55 10
ACx 601-0020-3
ACx 601-0025-5
ACx 601-0025-6
ACx 601-0025-3
ACx 601-0030-5
ACx 601-0030-6
16 4 14...20 0.55...0.79 1.5...1.8 1.1...1.3 16 4 10...14 0.39...0.55 16
ACx 601-0030-3
ACx 601-0040-5
ACx 601-0040-6
ACx 601-0040-3
ACx 601-0050-5
ACx 601-0050-6
ACx 601-0050-3
ACx 601-0060-5
Cu 35 *)
Al 50
Cu 2 *) 20...26 0.79...1.0 8 6 35 2 10...14 0.39...0.55 M6
ACx 601-0060-3
ACx 601-0070-5
ACx 601-0060-6
ACx 601-0070-3
ACx 601-0100-5
ACx 601-0070-6
70 2/0 26...35 0.79...1.4 8 6 35 2 10...14 0.39...0.55 M6
ACx 601-0100-3
ACx 601-0120-5
ACx 601-0100-6
ACx 601-0120-3
ACx 601-0140-5
ACx 601-0120-6
M10
1)
0375 30 22 70 2/0 M8
