Technical data
99
Input cable fuses
The ratings of UL listed fuses for branch circuit protection are listed below. The fuses
also prevent damage to the adjoining equipment of the drive in case of a short-circuit
inside the drive. Check that the operating time of the fuse is below 0.5 seconds.
The operating time depends on the supply network impedance and the cross-
sectional area and length of the supply cable. The fuses must be of the “non-time
delay” type. See also Planning the electrical installation: Thermal overload and
short-circuit protection.
Note 1: In multicable installations, install only one fuse per phase (not one fuse per conductor).
Note 2: Larger fuses must not be used.
Note 3: Fuses from other manufacturers can be used if they meet the ratings.
ACS800-U11 type
ACS800-11 type
Input
current
Fuse
A A V Manufacturer Type UL class
Three-phase supply voltage 208 V, 220 V, 230 V or 240 V
-0011-2 32 40 600 Bussmann JJS-40 T
-0016-2 44 70 600 Bussmann JJS-70 T
-0020-2 55 80 600 Bussmann JJS-80 T
-0025-2 70 90 600 Bussmann JJS-90 T
-0030-2 82 100 600 Bussmann JJS-100 T
-0040-2 112 150 600 Bussmann JJS-150 T
-0050-2 140 200 600 Bussmann JJS-200 T
-0060-2 157 200 600 Bussmann JJS-200 T
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
-0020-5 29 40 600 Bussmann JJS-40 T
-0025-5 33 50 600 Bussmann JJS-50 T
-0030-5 44 70 600 Bussmann JJS-70 T
-0040-5 54 80 600 Bussmann JJS-80 T
-0050-5 65 90 600 Bussmann JJS-90 T
-0060-5 76 100 600 Bussmann JJS-100 T
-0070-5 112 150 600 Bussmann JJS-150 T
-0100-5 129 200 600 Bussmann JJS-200 T
-0120-5 145 200 600 Bussmann JJS-200 T
PDM code: 00317419-C
