Electrical installation
Contents of this chapter
This chapter describes the wiring of the safety option done at the factory and contains
guidelines for making user connections (if any).
Wiring
One emergency stop button and one reset button are installed on the cabinet door and
wired to the FSO module at the factory. There are double contacts in the emergency stop
button and double wiring (redundant two-channel connection) between the button and the
FSO module.
There is an extension terminal block [X68] for the connections to the FSO module inside
the drive cabinet. The FSO module connectors [X113] and [X114] have been wired to [X68].
The tables below show the connections between the extension terminal block and the FSO
module.
10987654321FSO X113
13, 14, 15, 161211108, 976543X68
10987654321FSO X114
27, 28, 29, 3026252422, 232120191817X68
4
Electrical installation 41
