Technical data
74
Dimensions, weights, noise
See also the chapter Dimension drawings.
Note: The wiring to the I/O options requires some 50 mm (2”) of additional depth.
Cooling characteristics
Supply cable fuses
Fuses for short circuit protection of the supply cable are listed below. The fuses also
protect the adjoining equipment of the drive in case of a short circuit. Check that the
operating time of the fuse is below 0.5 seconds. The operating time depends on
the supply network impedance and the cross-sectional area and length of the supply
cable. See also chapter Planning the electrical installation.
Note: Fuses with a higher current rating must not be used.
Frame
size
Height Width
Depth
(without options
installed on
JCU)
Depth
(with options
installed on
JCU)
Weight Noise
mm (in.) mm (in.) mm (in.) mm (in.) kg (lbs) dB
E 700 (27.56) 313.5 (12.34) 398 (15.67) 415 (16.34) 67 (148) 65
Drive type
ACSM1-04xx…
Power
loss
Air flow
Minimum effective area
of air inlet
Minimum effective area
of air outlet
IP22 IP54 IP22 IP54
Wm
3
/h ft
3
/min cm
2
in
2
cm
2
in
2
cm
2
in
2
cm
2
in
2
-110A-4 1060 405 240
1000 155 2000 310 1600 250 3200 500
-135A-4 1590 405 240
-175A-4 2050 405 240
-210A-4 2570 405 240
Drive type
ACSM1-04xx…
Input
current
(A)
IEC fuse UL fuse Cross-sectional area of cable
Rated
current
(A)
Voltage
(V)
Class
Rated
current
(A)
Voltage
(V)
UL
Class
mm
2
AWG/MCM
-110A-4 107 160 500 gG 150 600 T 95…185 3/0 AWG…400 MCM
-135A-4 131 200 500 gG 200 600 T 95…185 3/0 AWG…400 MCM
-175A-4 171 200 500 gG 225 600 T 95…185 3/0 AWG…400 MCM
-210A-4 205 250 500 gG 300 600 T 95…185 3/0 AWG…400 MCM
