EtherNet/IP – Communication protocol 215
The format of the input assembly is:
16 DATA OUT 3 Value (Low Byte)
17 DATA OUT 3 Value (High Byte)
18 DATA OUT 4 Value (Low Byte)
19 DATA OUT 4 Value (High Byte)
20 DATA OUT 5 Value (Low Byte)
21 DATA OUT 5 Value (High Byte)
22 DATA OUT 6 Value (Low Byte)
23 DATA OUT 6 Value (High Byte)
24 DATA OUT 7 Value (Low Byte)
25 DATA OUT 7 Value (High Byte)
26 DATA OUT 8 Value (Low Byte)
27 DATA OUT 8 Value (High Byte)
28 DATA OUT 9 Value (Low Byte)
29 DATA OUT 9 Value (High Byte)
30 DATA OUT 10 Value (Low Byte)
31 DATA OUT 10 Value (High Byte)
Instance 172 (Transparent 32 profile)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Drive Profile 32-bit Status Word (Low Byte)
1 Drive Profile 32-bit Status Word
2 Drive Profile 32-bit Status Word
3 Drive Profile 32-bit Status Word (High Byte)
4 Drive Profile 32-bit Actual 1 Word (Low Byte)
5 Drive Profile 32-bit Actual 1 Word
6 Drive Profile 32-bit Actual 1 Word
7 Drive Profile 32-bit Actual 1 Word (High Byte)
Instance 122 (Transparent 32 profile)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
