ABB FENA-11 User Manual

EtherNet/IP – Communication protocol 187
The format of the input assembly is:
11 DATA OUT 4 Value (High Byte)
12 DATA OUT 5 Value (Low Byte)
13 DATA OUT 5 Value (High Byte)
14 DATA OUT 6 Value (Low Byte)
15 DATA OUT 6 Value (High Byte)
16 DATA OUT 7 Value (Low Byte)
17 DATA OUT 7 Value (High Byte)
18 DATA OUT 8 Value (Low Byte)
19 DATA OUT 8 Value (High Byte)
20 DATA OUT 9 Value (Low Byte)
21 DATA OUT 9 Value (High Byte)
22 DATA OUT 10 Value (Low Byte)
23 DATA OUT 10 Value (High Byte)
Instance 171 (ODVA AC/DC profile)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 At
Refer-
ence
Ref
From
Net
Ctrl
From
Net
Ready Run-
ning2
(Rev)
Run-
ning1
(Fwd)
Warn-
ing
Faulted
1 Drive State
See section State (Control supervisor object) on page 167.
2 Speed Actual (Low Byte)
3 Speed Actual (High Byte)
4 DATA IN 1 Value (Low Byte)
5 DATA IN 1 Value (High Byte)
6 DATA IN 2 Value (Low Byte)
7 DATA IN 2 Value (High Byte)
8 DATA IN 3 Value (Low Byte)
Instance 121 (ODVA AC/DC profile)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
