348 PROFINET IO – Communication protocol
Example 4: Configuring the process data written to the drive
PROFIdrive parameter 915 (393h) can be used to define which
data is written cyclically to a drive parameter as application-specific
process data.
In the example below, the value of drive parameter 12.06 (0C.06h)
is selected to be taken from PZD3. The parameter will continue to
be updated with the contents of PZD3 in each Request frame until
a different selection is made.
Subindex (IND) defines which process data word the required data
is taken from. Value selects the drive parameter to which that word
is mapped.
• DP-V1 Write request:
DP header
01 01 B0 2F 0E 0A 02 01 01 10 01 03 93 00 03 42 01 0C 06
DP trailer
DP-V1 Command PROFIdrive V3 Parameter Channel
Value
Number of
values
Format (42h =
Word)
Subindex
Parameter number
Number of elements
Attribute (10h = Value)
Number of parameters
Drive object ID
Request ID (02h = Change
Request reference
Slot number
Subslot number
Index
Data length
