PROFINET IO – Communication profiles 319
7 ALARM 1 Warning/Alarm
0 No warning/alarm
8 AT_SETPOINT 1 OPERATION. Actual value equals
reference (= is within tolerance limits, ie,
in speed control, speed error is 10%
max. of nominal motor speed).
0 Actual value differs from reference (= is
outside tolerance limits).
9 REMOTE 1 Drive control location: REMOTE (EXT1
or EXT2)
0 Drive control location: LOCAL
10 ABOVE_
LIMIT
1 Actual frequency or speed equals or
exceeds supervision limit (set by drive
parameter). Valid in both directions of
rotation.
0 Actual frequency or speed within
supervision limit
11 EXT_CTRL_
LOC
1 External Control Location EXT2 selected.
Note concerning ACS880: This bit is
effective only if the fieldbus interface is
set as the target for this signal by drive
parameters. User bit 0 selection (06.33)
0 External Control Location EXT1 selected
12 EXT_RUN_
ENABLE
1 External Run Enable signal received.
Note concerning ACS880: This bit is
effective only if the fieldbus interface is
set as the target for this signal by drive
parameters. User bit 1 selection (06.34)
0 No External Run Enable signal received
13…
14
Drive-specific (For information, see the drive documentation.)
15 FBA_ERROR 1 Communication error detected by
fieldbus adapter module
0 Fieldbus adapter communication OK
Bit Name Value STATE/Description
