ABB i-bus EIB User Manual

ABB i-bus
®
KNX
Commissioning
FCA/S 1.x.x.1 | 2CDC508134D0202 167
Extending staircase lighting time by
multiple operation ("Pumping up")
Options:
No (not retriggerable)
Yes (retriggerable)
Up to max. 2 x staircase lighting time
Up to max. 3 x staircase lighting time
Up to max. 4 x staircase lighting time
Up to max. 5 x staircase lighting time
If a further ON telegram is received during the staircase lighting time sequence, the remaining
staircase lighting time can be extended. This is possible by repeated actuation of the push button
(“pumping up“) until the maximum parameterized number of retriggering operations is reached. The
maximum time can be set to 1, 2, 3, 4 or 5 times the staircase lighting time.
Let's say the staircase lighting time has been extended by "pumping up" to the maximum time. If
some of the time has already elapsed, the staircase lighting time can be re-extended to the
maximum time by "pumping up" again. However, the parameterized maximum time may not be
exceeded.
 No (not retriggerable): The receipt of an ON telegram is ignored. The staircase lighting time
continues unmodified to completion.
 Yes (retriggerable): New ON telegrams reset the staircase lighting time and starts to count
again. This process can be repeated as often as desired using this selection.
 Up to max. 2/3/4/5 x staircase lighting time: New ON telegrams extend the staircase lighting
time by 2/3/4/5 times.
Staircase lighting time
in s [1…65,535]
Options:
1…30…65,535
The staircase lighting defines how long the contact is closed – provided that the output is
programmed as a normally open contact – and how long the light remains on after an ON telegram.
The input is made in seconds.
Staircase lighting can be switched
Options:
ON with 1 and OFF with 0
ON with 1, no action with 0
ON with 0 or 1, switch OFF not poss.
This parameter defines the telegram value used for switching the staircase lighting on and off
prematurely.
 ON with 0 or 1, switch OFF not poss.: The function Staircase lighting is switched on
independently of the value of the incoming telegram. Premature switch off is not possible.
