3.1.2 Output functions
The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator
and the application:
Functions of the output
A
B
C
D
General
- Overload


- Parallel operation

free

free
Valve drives allocated to the Fan Coil unit
- Thermoelectric (PWM)




- 1 control value/1 valve

free
free
free
- 2 control values/1 valve

free
free
free
- 2 control values/2 valves

free

free
- Analog (0…10 V)

-

-
- 1 control value/1 valve

-
free
-
- 2 control values/1 valve

-
free
-
- 2 control values/2 valves

-

-
Setting facilities for valve drives
- Thermoelectric (PWM)
- Separate heating/cooling




- Direction
OPEN/CLOSE
OPEN/CLOSE
OPEN/CLOSE
OPEN/CLOSE
- Motor-driven (3-point)
- Separate heating/cooling


- Direction
OPEN
CLOSE
OPEN
CLOSE
- Analog (0…10 V)
- Separate heating/cooling


- Direction
OPEN/CLOSE
OPEN/CLOSE
 = Function is supported
- = Function is not supported
free = Is available and can be used separately
Functions of the output
I
E
G
H
Switch function
Normally closed/ Normally open contact




Time
Staircase light




Fan
Level
1
2
3
-
 = Function is supported
- = Function is not supported
