ABB i-bus EIB User Manual

ABB i-bus
®
KNX
Device technology
48 2CDC508134D0202 | FCA/S 1.x.x.1
Operating and display elements
Button/LED
For assignment of the physical address
Button /LED
For toggling between manual
operation/operation via ABB i-bus
®
KNX and
displays
Button Output H / switch H
For switching and display
Fan speed button E, F, G
For switching the individual fan speeds
LED E, F, G
For display of fan speed 1, 2, 3
Buttons A, C
For opening/closing the valve
LED A, C
For displaying the valve position
Button /LED
For switching and display
Button /LED
For switching and display
Button /LED
For switching and display
Degree of protection
IP 20
To DIN EN 60 529
Protection class
II
To DIN EN 61 140
Isolation category
Overvoltage category
III according to DIN EN 60 664-1
Pollution degree
II to DIN EN 60 664-1
KNX safety extra low voltage
SELV 24 V DC
Temperature range
Operation
Transport
Storage
-5 °C…+45 °C
-25…+70 °C
-25…+55 °C
Temperatures exceeding +45 °C reduce the service life!
Ambient conditions
Maximum air humidity
93 %, no condensation allowed
Design
Modular installation device (MDRC)
Modular installation device, ProM
Dimensions
108 x 90 x 64.5 mm (H x W x D)
Mounting width in space units
6x 18 mm modules
Mounting depth
64.5 mm
Installation
On 35 mm mounting rail
To DIN EN 60 715
Mounting position
Any
Weight
0.3 kg
Housing/color
Plastic housing, gray
Approvals
KNX to EN 50 090-1, -2
Certification
CE mark
In accordance with the EMC guideline and low
voltage guideline
