ABB REB500 User Manual

1MRK 500 124-UEN Section 3
HMI500
Operation Manual 29
Distributed busbar protection REB500
3.5.7.4 Disturbance recorder file (Detailed view / Upload )
The disturbance records are available in a zipped Comtrade file. The involved
disturbance recorder files has the naming convention
DRyyyyMMddhhmmssfff_aaa_nnnnn.ZIP
Table 7 Disturbance file names
Item Description
yyyy
Year of the recording (Trigger time)
MM
Month of
the recording (Trigger time)
d
d
Day of the recording (Trigger time)
h
h
Hour of the recording (Trigger time)
mm
Minute of the recording (Trigger time)
s
s
Second of the recording (Trigger time)
fff
Miliseconds of the recording (Trigger time)
aaa
S
tation number
(1
-
999)
nnnnn
Fault number (0
-
65535)
The name of the file can be changed if the records are transferred manually.
3.5.8 Event list
Protection system events are shown in chronological order. By correspondingly
setting the event filter, just protection events, system events or test events can be
viewed separately. Events with an invalid time tag can be excluded from the
display. You can choose between “User-defined” and “System-defined” event
texts.
