69
Table 18.-1 Connectors (Continued)
Connector Meaning
X74 Time synch input
X75 HSTS Input
X76 HSTS Input
X77 HSTS Output
X80 Analog inputs
X81 Sensor 1
X82 Sensor 2
X83 Sensor 3
X84 Sensor 4
X85 Sensor 5
X86 Sensor 6
X87 Sensor 7
X88 Sensor 8
18.1. Analog Inputs
REF542plus can have a maximum of 8 analog input channels. These inputs
are divided into three measurement groups:
*
Measurement Group 1: channel 1, channel 2, channel 3
*
Measurement Group 2: channel 4, channel 5, channel 6
*
Measurement Group 3: channel 7, channel 8
Group 1 and group 2 have to be homogeneous, which means they can
measure 3 currents or 3 voltages. For example, measurements of 1 current
and 2 voltages are not allowed.
Group 3 can get any type of signals: 2 currents, 2 voltages, 1 current and 1
voltage and so on. Group 1 and group 2 can be used for homogeneous current
or voltage measurements both from instrument transformers and non-
conventional sensors. Group 3 can be used in a heterogeneous way.
Channel 7 and 8 in group 3 can be used for earth-fault current with CT type
input; residual voltage, or for the synchrocheck function with VT or sensor
type input.
The input CT 0.2A is commonly used with a toroidal transformer for
sensitive earth-fault current measurement.
Instrument current transformers can have secondary windings ratio /1 A or /5
A. The primary nominal current (for example 400 A) is selected with the
Operating Tool. The secondary current (for example /5 A) is automatically
selected connecting the right wire to the analog input module.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus
