ABB SPA-ZC 302 User Manual

1MRS755014
SPA-ZC 302
15
Profibus-DPV1/SPA Gateway
Installation and Commissioning
3. Installation
This chapter describes the mechanical installation of the SPA-ZC 302 module. It
also describes the electrical configuration of the gateway for different SPA bus types
and supply voltages. For additional information, refer to Chapter 7. Technical data
and Chapter 8. Maintenance and service.
3.1. Application
A Profibus-DPV1/SPA gateway is used to connect SPA bus devices to the Profibus
DP fieldbus.
A050290
Fig. 3.1.-1 Conceptual picture of a typical system setup
OPC Clients
OPC Server
Ethernet 1
Local Area Network
Ethernet 2
Controller Network
Engineering
Station
Profibus
Master
Profibus DP
SPA RS-485
SPA RS-232
SPA-ZC 302 SPA-ZC 302
REF 54x
Single SPA slave
SPA-ZC 21
Multiple SPA slaves on SPA Loop connection
21
SACO 64D4 Annunciator
Multiple SPA slave modules
21
SPA-ZC 302
