ABB SPA-ZC 302 User Manual

1MRS755014
SPA-ZC 302
57
Profibus-DPV1/SPA Gateway
Installation and Commissioning Manual
7. Technical data
7.1. Interfaces
Profibus DP version 1 interface
• RS-485 twisted pair
• 9-pin female D-connector
SPA bus interface
• RS-232, RS-485 or TTL levels
• 9-pin female D-connector
7.2. Power supply
SPA-ZC 302
• Input voltage: 110 V...240 V AC/DC
• Output voltage (conf. with DIP switch 1.5): +8 V DC unregulated from pin 9
(RS-485, TTL)
• Supply current consumption: <80 mA
Table 7.2.-1 Environmental conditions
Specified ambient service temperature range -10...+55ºC
Transport and storage temperature range -40...+70ºC
Maximum relative humidity (without condenzation) 95%
Table 7.2.-2 Environmental tests
Dry heat test according to IEC 60068-2-2 +55ºC
Dry cold test according to IEC 60068-2-1 -10ºC
Damp heat test according to IEC 60068-2-30 RH > 93%, 55ºC, 6 cycles
Degree of protection by enclosure of the device case according
to IEC 60529 IP20
Table 7.2.-3 Electromagnetic compatibility tests
The EMC immunity test level fulfils the requirements specified below
1 MHz burst disturbance test,
class III, IEC 60255-22-1
common mode 2.5 kV
differential mode 1.0 kV
Electrostatic discharge test,
class III, IEC 61000-4-2 and
IEC60255-22-2
for contact discharge 6 kV
for air discharge 8 kV
