Machine Maintenance 3-93
3. Secure the ODD bracket with the one screw.
Figure 3-145. ODD Bracket Screw
4. Slide the optical drive into the drive bay until the ODD bezel is flush against the lower
case.
Figure 3-146. ODD Module
Table 3-37. Screw
Step Screw Quantity Screw Type
ODD Bracket Assembly M2 × L3 1
