3-20 Machine Maintenance
Removing the Keyboard 0
The keyboard is easily warped or damaged during the removal process. Take
care not to use excessive force when removing.
1. Perform the “Removing the Base Door” procedure described on page 3-13.
2. Remove the screws securing the keyboard.
Figure 3-22. Keyboard Screws
3. Turn the computer over and open the LCD panel.
Table 3-10. Screws
Step Screw Quantity Screw Type
Keyboard Disassembly M2.5 × L6 2
To Next Page
