Acer Aspire 5755 User Manual

1-32 Hardware Specifications and Configurations
LED 15.6”
Display Supported Resolution (LCD)
Item Specification
Vendor/Model name
 AUO/B156XW02 V6 (HW:0A)
 AUO/B156XW02 V2 (HW:4A)
 Samsung/LTN156AT02-A11
 LG/LP156WH2-TLEA
 CMO/N156B6-L0B
 CPT/ CLAA156WB11A
Screen Diagonal (mm) 394.91 mm
Active Area (mm) 344.23 mm x 193.54 mm
Display resolution (pixels) 1366 x 3(RGB) x 768
Pixel Pitch (mm) 0.252mm × 0.252 mm
Typical White Luminance (cd/m
2
)
also called Brightness
200 cd/m
2
Contrast Ratio 400 min / 500 type
Response Time (Optical Rise
Time/Fall Time) msec
8 ms / 16 ms
Typical Power Consumption
(watt)
5.15 W
Weight (without inverter) 460 max
Physical Size (mm) 360 mm x 210mm x 5.5 max
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right) CR = 10 (Left)
Vertical (Upper) CR = 10 (Lower)
40 (Right) / 40 (Left) / 10 (Upper) / 30 (Lower) min.
Resolution 16 bits 32 bits 36 bits 48 bits Others
800x600p/60Hz 16:9 V V V V V
1024x768p/60Hz 16:9 V V V V V
1280x600/60Hz 16:9 V V V X X
1280x720/60Hz 16:9 V V V V V
1280x768/60Hz 16:9 V V V V V
1360x768/60Hz 16:9 V V V V V
1366x768/60Hz 16:9 V V V V V
Legend: V = Supported; X = Not supported
SG_JV51_HR.book Page 32 Friday, July 8, 2011 5:58 PM

Acer Aspire 5755 Specifications

General

RAM	Up to 8 GB DDR3
Display	15.6-inch HD (1366 x 768)
Graphics	Intel HD Graphics 3000 or NVIDIA GeForce GT 520M / 540M
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Optical Drive	DVD-Super Multi DL drive
Chipset	Intel HM65 Express
LAN	Gigabit Ethernet
Webcam	1.3MP
Processor	Intel Core i3/i5/i7
Weight	2.6 kg
Ports	3 x USB 2.0, HDMI, VGA
Wireless	Wi-Fi 802.11b/g/n
Card Reader	SD, MMC
Storage	320 GB, 500 GB, 640 GB, 750 GB HDD
