Chapter 5
93
Aspire 5810TG T
op View
No.
Code
Connector
1
SPK1
S
peaker cable connector
2
KB1
Keyboard cable con
nector
3
TP1
T
o
uchpad cable connector
4
CN1
Card reader cable connector
5
CN3
CRT cable connector
6
CN2
CRT cable connector
7
F
AN1
Thermal
module fan cable
connector
8
LCD1
LCD cable connector
9
BTB2
Power button cable co
nnector
100
102
