Chapter 1 7
Left View
# Icon Item Description
1 Kensington lock
slot
Connects to a Kensington-compatible computer security
lock.
Note: Wrap the computer security lock cable around an
immovable object such as a table or handle of a locked
drawer. Insert the lock into the notch and turn the key to
secure the lock. Some keyless models are also
available.
2 USB 2.0 port Connect to USB 2.0 devices (e.g., USB mouse, USB
camera).
3 Ventilation slots Enable the computer to stay cool, even after prolonged
use.
4 External display
(VGA) port
Connects to a display device (e.g., external monitor,
LCD projector).
5
HDMI
HDMI port Supports high definition digital video connections.
6 USB 2.0 port Connect to USB 2.0 devices (e.g., USB mouse, USB
camera).
7
Microphone-in jack
Accepts inputs from external microphones.
Headphones/
speaker/line-out
jack with S/PDIF
support
Connects to audio line-out devices
(e.g., speakers, headphones).
