Chapter 3 41
External Module Disassembly Process
External Modules Disassembly Flowchart
The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you
on the components that need to be removed during servicing. For example, if you want to remove the main
board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.
Screw List
Item Screw Color Part No.
A M2.5 x L6 Black 86.00E69.736
C M3 x L4 Silver 86.9A524.4R0
D M2 x L3 Silver 86.9A552.3R0
H M2.5 x L11 Black 86.1A353.110
EXTERNAL MODULE DISASSEMBLY
SSD
MODULE
TURN OFF POWER
AND PERIPHERALS
UNPLUG POWER
CABLES
LOWER
COVER
Captive Screwx4
DIMM
MODULES
REMOVE BATTERY
PACK
Dx1
ODD
MODULE
OPTICAL DISK
DRIVE
OPTICAL
LOCKER
BRACKET
Cx2
HDD
MODULE
HARD DISK
BRACKET
HARD DISK
DRIVE
Ax1
RTC
BATTERY
Hx4
To Next Page
