Chapter 3 69
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Item Screw Color Part No.
E M2 x L2.5 Silver 86.9A526.2R5
F M2.5 x L2.5 Black 86.00F87.735
G M2.5 X L3.5 Silver 86.9A563.3R5
LCD MODULE
LCD BEZEL
Gx4
LCD ASSEMBLY
LCD FPC
CABLE
LCD MODULE DISASSEMBLY
WEB
CAMERA
LEFT HINGE
RIGHT HINGE
Fx2
Fx2
Ex4
