Acer Aspire 7740G Series User Manual

48 Chapter 3
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Item Screw Color Part No.
A M2.5 x L6 Black 86.00E12.536
B M2.5 x L10 Black 86.00F84.73A
C M2.5 x L4 Black 86.00H59.734
D M2.5 x L3.5 Silver 86.9A563.3R5
F M2 x L4 Silver 86.9A552.4R0
G M2 x L3 Silver 86.9A522.3R0
MAIN UNIT
MAIN UNIT DISASSEMBLY
HEATSINK
MODULE
CPU
SCREW x 7
MIDDLE COVER
C x 3
KEYBOARD
LCD MODULE
A x 2, B x 4
MAIN
BOARD
G x 2
UPPER CASE
A x 16, C x 2
TOUCHPAD
BASEBOARD
F x 2
TOUCHPAD
MODULE
MODEM
CARD
F x 2
F x 2, D x 1
BLUETOOTH
BOARD
USB
BOARD
C x 1
LEFT
SPEAKER
F x 2
MICROPHONE
RIGHT
SPEAKER
C x 2

Acer Aspire 7740G Series Specifications

General

Memory	Up to 8GB DDR3
Storage	Up to 640GB HDD
Battery	6-cell Li-ion
Wireless	802.11b/g/n Wi-Fi
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Processor	Intel Core i3/i5/i7
Graphics	ATI Mobility Radeon HD 5650
Display	17.3" HD+ (1600 x 900) / Full HD (1920 x 1080)
Optical Drive	DVD Super Multi DL
Operating System	Windows 7 Home Premium / Professional
Chipset	Intel HM55
Card Reader	Multi-in-1 card reader
Ports	HDMI, VGA, Ethernet
