Chapter 3 79
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Item Screw Color Part No.
E M2.5 x L5 Black 86.00F87.735
G M2 x L3 Silver 86.9A522.3R0
LCD MODULE
LCD BEZEL
E x 6
LCD ASSEMBLY
LEFT LCD
BRACKET
G x 3
RIGHT LCD
BRACKET
LCD FPC
CABLE
LCD BACK PANEL
ANTENNAS
LCD MODULE DISASSEMBLY
WEB
CAMERA
LEFT HINGE
RIGHT HINGE
E x 2
E x 2
G x 3
