32 Chapter 1
Hardware Specifications and Configurations
Processor
Second Level Cache
System Memory
Lan Interface
Item Specification
CPU type Intel CPU Penryn
Core logic Intel 975PM + ICH9M
CPU package uFCPGA, Socket P
CPU core voltage 0.944~1.3V
Item Specification
Cache controller Built-in CPU
Cache size 6MB
1st level cache control Always enabled
2st level cache control Always enabled
Cache scheme control Fixed in write-back
Item Specification
Memory controller Intel PM975
Memory size 0MB (no on-board memory)
DIMM socket number 2 sockets
Supports memory size per socket 2GB
Supports maximum memory size 4GB
Supports DIMM type DDR 3 Synchronous DRAM
Supports DIMM Speed 800/1066 MHz
Supports DIMM voltage 1.8V and 0.9V
Supports DIMM package 200-pin soDIMM
Item Specification
Chipset ATHEROS_AR8121
Supports LAN protocol 10/100/1000 Ethernet
PCI-E Giga
LAN connector type RJ45
LAN connector location Left side
Features Integrated 10/100/1000 BASE-T transceiver
