No. Item Description
1 Power button Long press to turn the tablet on, press briefly to
turn the screen on/off or enter sleep mode; press
and hold to turn the tablet off.
2 3.5 mm headphone jack Connects to stereo headphones.
3 Micro HDMI (Type D)
connector
Connects to an HDMI cable with a Type D
connector.
4 Card slot cover Insert a microSD card into the slot under this
cover. See "Inserting a microSD card (optional)"
on page 25.
A SIM card slot (only for Wi-Fi+3G models) allows
you to access the Internet if you have a cellular
data subscription. The underside of the slot cover
contains the tablet’s serial ID number, which is
necessary when servicing.
No. Item Description
1 Volume control key Increases and decreases the tablet volume.
2 Screen rotation lock
switch
Use this switch to lock the screen rotation or
allow the screen to match the tablet’s orientation.
3 Microphone Receives audio for video chats and Internet calls.
