Chapter 1 4
Connection Ports
Item Description
1
DVI Input Connector (for Digital signal with HDCP function)
(Optional)
2 PC Analog Signal / HDTV / Component Video Input Connector
3 Audio Input Connector
4 S-Video Input Connector
5 Monitor Loop-through Output Connector
6 USB Connector
7 Remote Control IR Receiver
8 Composite Video Input Connector
9 Kensington
TM
Lock Port
10 5V DC Output Jack (dfor attached dongle device) (for PD100 only) (for PD120 only)
To Next Page
